SPECIFICATIONS


  Designed and built to ...

- load manure, for yourself and others
- drain irrigation channels and ditches
- transport and stack roll-bars
- load scrap in deposits and foundries
- stack and load beet in fields
- carry out industrial and civil excavations in urban and rural centres
- stack and load timber in sawmills
- re-arrange, move and uproot plants in nurseries

  Features:
- outriggers on front and rear axles
- hydraulic trasmission with two-speed mechanical gearbox
- double cylinder for activating 2nd arm
- large driving seat (comfort-type seat)
- bulldozer blade on rear axle
- switches for selecting fork cylinder or excavator cylinder
- special tyres for rice fields



Engine


- 4 cylinder diesel
- 80 HP
- 12 V electric starting
- fuel tank capacity 70 lt.



Hydraulic system


- sump capacity 230 lt.
- working pressure 180/450 bar
- visible oil level in sump
- control valve with anti-cavitation and shockproof valves on each user
- 3 independent circuits:


. translation
. auxiliary duties
. steering



Drive


- hydrostatic in circuit with continuous delivery pump
- variable displacement pump with hydraulic servo control
- axial piston engine with 2-speed mechanical gearbox selected from driving seat (pneumatic clutch)
- speed 0÷8 - 0÷15/18 km/h



Differential axles


- rigid rear axle
- steering and oscillating front axle with hydraulic lock



Tyres


- F 20 - alternatively 16/70-20



Brakes


- hydro-pneumatic system with pedal and manual stationary control on the four wheels



Rotation


- 360° continuous with radial piston and epycycloidal reduction gear on fifth Ø 1000, hardened with 2 ball revs



Cab


- tilting type, with rearview mirror and windscreen wiper
- instruments:



. control panel
. oil pressure gauge
. positin light
. headlights
. flashing light
. direction indicator
. horn ...




Controls


- 2-lever control stick for main duties
- secondary control valve for auxiliary duties



Hydraulic circuit cooling



- consists of heat exchanger with preset thermostat fitted i trasmission circuit



Optionals


- bulldozer blade on rear axle
- hydraulic supports on rear axle
- hydraulic servo control with mechanical hands
- heated cab
- preset hydraulic turning for bucket
- hydraulic telescopic forearm
- arm extensions
- on request implements for all work purposes



Approved for circulation on road
